20a Ac Circuit Breaker
- Compact design, space saving and easy installation - Safety protection for your circuit escort, effectively prevent circuit overload and short circuit
- Suitable for home, commercial and industrial applications to ensure the safe operation of your electrical equipment
Specifications
|
DZ47-63AC Series Circuit Breaker |
DZ47-63AC |
|
|
Frame Degree Rated Current (A) |
125A |
|
|
Pole |
IP, 2P, 3P 4P |
|
|
Rated Operating Voltage (VDC) |
lP250\2P500\3P750\4P1000V |
|
|
Rated Current In (A) |
1,2,3,4,6,10,16,20,25,32,40,50,63,80,100,125 |
|
|
Rated Insulation Voltage Ui (VDC) |
12VAC |
|
|
Rated Impact Voltage Uimp (kV) |
4kV |
|
|
Ultimate Breaking Capacity leu (kA) |
4.5kA/6kA |
|
|
Run Breaking Capacity les (%lcu) |
75% |
|
|
Curve Type |
C |
|
|
Trip Type |
Thermal-magnetic |
|
|
Mechanical Life |
Actual Average Value |
20000 |
|
Standard Value |
8500 |
|
|
Electric Life |
Actual Average Value |
6000 |
|
Standard Value |
2500 |
|
Condition and Installation
|
Wiring Capacity (mm2) |
32A, 1~25 mm2J^40A, 10~35mm2 |
||||
|
Ambient Temperature (*C) |
-20-+70 |
||||
|
Altitude |
^2000 |
||||
|
Relative Humidity |
W95% |
||||
|
Pollution Level |
3 |
||||
|
Installation Environment |
No obvious shock and vibration |
||||
|
Installation Category |
Class III |
||||
|
Installation |
DIN Standard rail |
||||
|
Dimensions(W)x(H)x(Deep) |
W |
18 |
36 |
54 |
72 |
|
H |
80 |
80 |
80 |
80 |
|
|
c |
71 |
71 |
71 |
71 |
|
|
Weight (kg) |
0.12 |
0.24 |
0.36 |
0.48 |
|
